Mozec

Crossability

Mozec is the Rx PTCA semi-compliant balloon dilatation catheter from Meril, manufactured in-house from tip-to-hub.

• Ultra-low 0.019” distal tip ensures navigations through tight lesions
• Small abrupt balloon shoulders lower the crossing profile allowing for most competitive crossing ranges.

Distal Shaft Coating

MeriGlideTM – Biocompatible, Hydrophilic, Lubricious Coating distal balloon base up to Rapid Exchange port

less than 4 µm thick. It is non-thrombogenic which resists adsorption of fibrin and platelet adhesion


Wrapability

• Excellent Balloon Wrapability
• 2 folds for Ø 1.25 to 2.00 mm
• 3 folds for Ø 2.25 to 4.50 mm
• Folds are in clock-wise direction when seen from the distal tip
• Special balloon material NovalonTM ensures
– Low wrapping profile of folded balloon
– Memory retention after serial dilatation

Inflation / Deflation Time

Best in class inflation time (10 secs) & deflation time (25 secs) for largest configuration 4.50 x 41 mm

Seamless Single Tube Transition

The distal tubing is a single transparent transitioning tube from the end of hypotube.

This allows for superior force transmission without any loss during navigation

FeatherGlideTM – Seamless catheter construction technology allows for exceptionally low tracking forces of 0.35N

FeatherLiteTM – Construction which generates high push transfer capability and reducing the push forces to less than 0.08N

MeriStemTM – Novel Shaft Material increased strength and kink resistance

Hub

• Proprietary unique ergonomic design – Meril’s “sign-of-life” ECG Bubble
shape, transparent luer hub.

• Etched logos – which allow for slip-free grip.

• Strain relief ensures secure and smooth kink resistant transition towards the
proximal shaft.

• Batch number and Size dimensions are printed on one side.

Mozec for CTO application

• Small diameters of 1.25 mm and 1.50 mm
• Short lengths starting from 6 mm
• Specially elongated 5mm tip
– Provides distal stability and support (micro-catheter)
– Crosses the lesion prior to balloon crossing
• MeriStemTM hypo-tube shaft for enhanced support and pushability
• MeriStemTM coated hydrophilic distal shafty
• Two fold balloon with excellent wrap memory
• Single centrally placed swaged zero profile RO marker band

A World Class PTCA Balloon Catheter Manufactured In A World Class Facility

• Located within Meril’s ultra-modern stent manufacturing facility, MOZEC balloon catheter is built under the guidance from the most experienced in the
catheter technology.
• Tip-to-hub, this Rx balloon dilatation catheter is designed for meeting and surpassing the best industry standards.
• Each catheter undergoes 100% in-process quality inspection to detect and weed out the defects at every manufacturing step.
• Thus the final balloon catheter becomes the right means for a meaningful procedure.

Technical Specification

Catheter System Rapid Exchange (Rx)
Balloon Material NovalonTM – Semi-Compliant
Catheter Length Working length 142 cm
Total length 149 cm
Guide Catheter Compatibility 5F (Min I.D. 0.056” / 1.42 mm)
*Kissing balloon Technique using 2 simultaneous MOZEC Balloons of 3.50 mm
Diameters is possible with a 6F Guide catheter (min I.D. 0.070” / 1.78 mm)
Distal Shaft Coating MeriGlideTM - Biocompatible, Hydrophillic, Lubricious from distal Balloon Base upto Rapid Exchange port
Balloon RO Markers Platinum - Iridium, Swaged and zero profile
1 for Ø 1.25 & 1.50 mm, 2 for mm Ø 2.00 to 4.50 mm
Tip Length 5 mm for Ø 1.25 to 2.00 mm, 3.5 mm for Ø 2.25 to 4.50 mm
Tip entry Profile 0.019”
Proximal Shaft Diameter 1.98 Fr
Distal Shaft Diameter 2.4 Fr for Ø 1.25 to 2.00 mm, 2.7 Fr for Ø 2.25 to 4.50 mm
Markers on Proximal Shaft Brachial and Femoral markers 90 cm and 100 cm from Distal Tip.
Nominal Pressure (NP) 7 ATM for all diameters
Rated Burst Pressure (RBP) 16 ATM Ø 1.25 to 4.00 mm, 14 ATM Ø 4.50 mm

Configurations

Dia / Length 6mm 9mm 12mm 14mm 15mm 17mm
1.25 mm MOZ12506 MOZ12509 MOZ12512 MOZ12515
1.50 mm MOZ15009 MOZ15012 MOZ15015
2.00 mm MOZ20009 MOZ20012 MOZ20015
2.25 mm MOZ22509 MOZ22514 MOZ22517
2.50 mm MOZ25009 MOZ25014 MOZ25017
2.75 mm MOZ27509 MOZ27514 MOZ27517
3.00 mm MOZ30009 MOZ30014 MOZ30017
3.50 mm MOZ35009 MOZ35014 MOZ35017
4.00 mm MOZ40009 MOZ40014 MOZ40017
4.50 mm MOZ45009 MOZ45014 MOZ45017

Dia / Length 20mm 25mm 30mm 33mm 38mm 41mm
2.25 mm MOZ22520 MOZ22525 MOZ22530 MOZ22533 MOZ22538 MOZ22541
2.50 mm MOZ25020 MOZ25025 MOZ25030 MOZ25033 MOZ25038 MOZ25041
2.75 mm MOZ27520 MOZ27525 MOZ27530 MOZ27533 MOZ27538 MOZ27541
3.00 mm MOZ30020 MOZ30025 MOZ30030 MOZ30033 MOZ30038 MOZ30041
3.50 mm MOZ35020 MOZ35025 MOZ35030 MOZ35033 MOZ35038 MOZ35041
4.00 mm MOZ40020 MOZ40025 MOZ40030 MOZ40033 MOZ40038 MOZ40041
4.50 mm MOZ45020 MOZ45025 MOZ45030 MOZ45033 MOZ45038 MOZ45041
